This compact nebulizer with practical handle is equipped with a glove compartment for placing accessories. Design is simple and with no-frills.
Practical handle for a simple design.
What's in the box.
Air connection
Linear medicine cup
Adult mask
Pediatric mask
A120
Nose piece
Mouth piece
OPTIONAL
Nasal washer
Adjustable medicine cup
Tech specs.
DIMENSIONS
WEIGHT
MOTOR
DRUG RESIDUES
MAX AIR PRESSURE
OPERATING PRESSURE
MAX AIR FLOW
OPERATING CYCLE
SOUND NOISE LEVEL
275 x 220 x 97 mm
1,5 Kg
AC 230 V - 50 Hz - 120 VA
0,3 ml
1,7 ± 2,3 bar
0,5 / 0,7 bar
13 ± 17 l/min
20 min ON / 40 min OFF
59 dB
This product is compliant with the safety requirements and electromagnetic compatibility (EMC + EMF) request by EU Regulation for Medical Devices.
Medical Device class lla (MDD 93/42/ECC).
PARTICLE DIMENSIONS
< 5 MMAD
WORKING CONDITIONS
Ambient temperature min 5°C - max 40°C
Air umidity min 15% RH - max 93% RH
Atmospheric pressure min 700 hPa - max 1060 hPa
MAINTENANCE CONDITIONS
Ambient temperature min -25°C - max 70°C
Air umidity min 0% RH - max 93% RH
Atmospheric pressure min 500 hPa - max 1060 hPa
FINISHING
- Dust light blue
DOWNLOAD
Technical data sheet
DOWNLOAD
Instructions manual
