This little and compact nebulizer concentrates all the functions of its category in a very little volume. White and form cleanliness rule.

Essential design in a white form.

What's in the box.

Air connection

Adult mask

Pediatric mask

Linear medicine cup

A200

Nose piece

Mouth piece

OPTIONAL

Nasal washer

Adjustable medicine cup




Tech specs.

DIMENSIONS

WEIGHT



MOTOR

DRUG RESIDUES

MAX AIR PRESSURE

OPERATING PRESSURE

MAX AIR FLOW

OPERATING CYCLE

SOUND NOISE LEVEL

130 x 130 x 100 mm

1,3 Kg



AC 230 V - 50 Hz - 120 VA

0,3 ml

1,7 ± 2,3 bar
0,5 / 0,7 bar
13 ± 17 l/min


20 min ON / 40 min OFF
57 dB

This product is compliant with the safety requirements and electromagnetic compatibility (EMC + EMF) request by EU Regulation for Medical Devices.

Medical Device class lla (MDD 93/42/ECC).

PARTICLE DIMENSIONS

< 5 MMAD



WORKING CONDITIONS

Ambient temperature min 5°C - max 40°C

Air umidity min 10% RH - max 95% RH

Atmospheric pressure min 700 hPa - max 1060 hPa



MAINTENANCE CONDITIONS

Ambient temperature min -25°C - max 70°C

Air umidity min 0% RH - max 93% RH

Atmospheric pressure min 500 hPa - max 1060 hPa

DOWNLOAD

Technical data sheet

DOWNLOAD

Instructions manual
