Looking for

softness.

This nebulizer discloses a unique design: soft forms which remember something familiar and homely. The practicle handle gets the product easy to carry.

What's in the box.

Air connection

Linear medicine cup

Adult mask

Pediatric mask

A610

Nose piece

Mouth piece

OPTIONAL

Nasal washer

Adjustable medicine cup




Tech specs.

DIMENSIONS

WEIGHT



MOTOR

DRUG RESIDUES

MAX AIR PRESSURE

OPERATING PRESSURE

MAX AIR FLOW



OPERATING CYCLE

SOUND NOISE LEVEL

190 x 178 x 102 mm

1,3 Kg



AC 230 V - 50 Hz - 120 VA

0,3 ml

1,7 ± 2,3 bar
0,5 / 0,7 bar
13 ± 17 l/min


20 min ON / 40 min OFF
57 dB

This product is compliant with the safety requirements and electromagnetic compatibility (EMC + EMF) request by EU Regulation for Medical Devices.

Medical Device class lla (MDD 93/42/ECC).

PARTICLE DIMENSIONS

< 5 MMAD



WORKING CONDITIONS

Ambient temperature min 5°C - max 40°C

Air umidity min 15% RH - max 93% RH

Atmospheric pressure min 700 hPa - max 1060 hPa



MAINTENANCE CONDITIONS

Ambient temperature min -25°C - max 70°C

Air umidity min 0% RH - max 93% RH

Atmospheric pressure min 500 hPa - max 1060 hPa

FINISHING

- Dust light blue

DOWNLOAD

Technical data sheet

DOWNLOAD

Instructions manual
